• Model: CKCS BS01
• Type: Mini Boost Converter
• Output Voltage Options: 5V, 8V, 9V, 12V (fixed)
• Input Voltage Range: 3.7V (minimum) to 5.5V (maximum)
• Output Current: 1.5A (maximum)
• Operating Temperature: -20°C to +85°C
• Dimension: 22mm/11mm

PRODUCT FEATURES:

• 100% Brand New And Super High Quality.
• The Output Voltage Can Be Set To 5V/8V/9V/12V, The Default Is 12V.
• input Voltage Range: 2.5V~V OUT-0.5V.
• Take 3.7V Lithium Battery Input As An Example, It Can Output 5V 1A, 8V 0.5A, 9V 0.4A, 12V 0.3A.
• Make Sure That The Input Current And Output Current Do Not Exceed 1.5A.
• The Pad Next To The LED Indicator Can Also Be Turned Off To Turn Off The Indicator.

BASIC PARAMETERS:

The output voltage can be set to 5V/8V/9V/12V, the default is 12V.

Input voltage range: 2.5V~5V OUT.

The input voltage must be lower than the set output voltage.

When inputting 3.7V lithium battery, it can output 5V 1A, 8V 0.5A, 9V 0.4A, 12V 0.3A.

When inputting at 5V, it can output 8V 0.7A, 9V 0.7A, 12V 0.5A.

When the default 12V output, the LED indicator consumes about 1mA.

If the indicator is turned off, the input current is <1mA at no load.

Basic parameters

The output voltage can be set to 5V/8V/9V/12V, the default is 12V

Input voltage range: 2.5V~VOUT-0.5V

Output performance: Take 3.7V lithium battery input as an example, it can output 5V1.2A, 8V0.7A, 9V0.6A, 12V0.5A. Make sure that the input current and output current do not exceed 1.5A.

Voltage setting description

The front side of the PCB can be seen with the words A and B. The output voltage can be changed by using the soldering iron to change the pad on and off. In the following table, 0 means the pad is disconnected and 1 means the pad is connected.

A B VOUT

0 0 5V

0 1 8V

1 0 9V

1 1 12V
