24W max (hw-298) 3.0 QC2.0 1USB DC-DC BUCK CONVERTER CHARGING STEP DOWN MODULE 6-32V 9V 12V 24V TO FAST QUICK CHARGER CIRCUIT BOARD 3V 5V 12V ONE C...

• input voltage range: 6V to30V
• Output voltage: The default is 5V. After the fast charge is triggered, it is automatically adjusted between 3 and 12V.
• Output Power. 24W (5V, 3.4A, 9V, 2.5A, 12V, 2A, etc.)
• Conversion efficiency: 90% to 97%
• Supports multiple fast charging protocols
• Input overvoltage, undervoltage protection
• Input over-current protection
• Output overcurrent and short circuit protection
• Over temperature protection

Product Description

Input voltage range: 6V-32V.

Output voltage: default 5V, automatically adjust between 3-12V after triggering fast charge.

Output power: maximum 24W ([email protected], [email protected], 12V@2A, etc.).

Wired function of output voltage.

Conversion efficiency: 90%-97%.

Support a variety of fast filling protocols.

Overvoltage and undervoltage protection.

Input over current protection.

Output overcurrent and short circuit protection.

Over temperature protection for the whole machine.

Support: BC1.2, QC2.0, QC3.0, MTK PE+1.1, MTK PE+2.0, FCP, AFC, SFCP.

Product Size: 34*17*9.5mm (Excluding 1mm of USB female seat protrusion).

Applications :

Solar panel to mobile phone charging.

Car charging retrofit.

Driving recorder power supply.

Home power conversion.
